BKCL-2800&4500(Horizontal Type)
Features
ㆍNo shaking of machine during high speed swing operation, due to its reinforced frames. Accurate swing performance helps to produce uniformity thickness and width of products.
ㆍThe conveyor contains anti-static electricity belt which is light and precise. It also shows great performance during high speed swing.
ㆍBy using a brake motor, bottom conveyor moves vertically for boosting working convenience.
Drawings
Specifications
| Working width | 100" & 80" X 2,800 mm | 100" & 80" X 4,500 mm | 100" & 80" X 6,000 mm | 100" & 80" X 8,000 mm |
| Speed | 60M/Min | 70M/Min | 80M/Min | 80M/Min |
| Electric power |
1.5kw-3Set, 2.2kw-1Set, B/K 0.75kw-2Set |
1.5kw-3Set, 3.75kw-1Set, B/K 1.5w-2Set |
2.2kw-3Set, 5.5kw-1Set, B/K 1.5kw-2Set |
2.2kw-3Set, 5.5kw-1Set, B/K 1.5kw-2Set |
| Main product | For geotextile, embedding materials for automobiles, clothes, carpets, padding, felt. | |||
■ Specifications of this machine can be changed for quality improvement.
